MCKB012 / NXP Key Programmer For Nissan / Remote Adding Tool

The MCKB012 is a specialized, solder-free NXP smart key adapter designed specifically for modern Ford and Lincoln vehicles. It features a custom workbench layout that allows automotive locksmiths to securely clamp down the remote's circuit board and interface directly with its security components without requiring any manual soldering.

FCC ID Information

Commonly associated FCC IDs: KR5TXPZ1, KR5TXPZ2, KR5TXPZ3, KR5TXPZ4

These FCC IDs are not interchangeable for vehicle programming. However, the MCKB012 may support multiple versions when their NCF29xx circuit boards match the adapter.

Specifications

Part Number: MCKB012

Application: Newer Nissan and Infiniti smart remotes

Approximate Model Years: 2022 and newer

Remote Style: Select 2, 3, 4, and 5-button configurations

Common Frequency: 433/434 MHz

Supported Chip Series: NXP NCF29xx

Board Version: 12-NS1-V2.0

Connection Type: Direct, solder-free PCB contact

Contact Points: VCC, MSDA, WAKE, GND, and MSCL

Contact Method: Gold-plated, spring-loaded pogo pins

Holding Mechanism: Spring-loaded clamps

Primary Functions: Reading, writing, unlocking, cloning, and remote adding when supported by the connected tool

Compatible Tools: Supported KYDZ, KeyDIY, VVDI, and similar NXP programming devices

Condition: New

Package Includes: One MCKB012 Nissan/Infiniti smart-key adapter

Please Note: Compatibility depends on the remote’s NCF29xx chip and circuit-board layout. Vehicle model, year, FCC ID, frequency, or button count alone does not guarantee compatibility. The programming device and smart remote are sold separately.
